Utility BOARD ASSISTANT TOOLS FOR ALTIUM DESIGNER

Automate work in Altium Designer saves time for electronics developers

BOASTOOLS is a software package that allows you to automate the design process in Altium Designer. It is a tool that saves the engineer from routine work and leaves time and space for creativity.

DOWNLOAD
VIDEO

BOASTOOLS FIT EXACTLY FOR YOUR PROJECT

The peculiarity of the solution is the absence of requirements for design, maintenance of libraries, etc. Without any additional time, and therefore financial costs, you can comply not only with national requirements.
PROFESSIONAL SOLUTION
The product was created by GlavKon, the official representative of Altium Limited in Russia since 2016.
LICENSE PRODUCT
Availability of technical support, official registration for a legal entity.
UNIVERSALITY
Complements Altium Designer without transferring information to third-party software solutions.
BENEFIT
BOASTOOLS saves design time

HOW DO I LEARN TO WORK IN BOASTOOLS?

The software package was created in order to simplify the work of electronics designers. That is why it was important for us as developers not to complicate our acquaintance with BOASTOOLS, but to make it as simple and convenient as possible.
Board Assistant has an intuitive interface. To quickly get to know the product's capabilities will help:
Telegram group
YouTube Tutorial Videos
What's included in Boastools?
We are constantly working on increasing the utilities, so we will be glad to see your ideas.
  • Trim Silkscreen
    Removal of technologically unnecessary parts of silkscreen from the PCB. Such as inside the holes, inside the board cutouts, as well as at an adjustable distance from the solder mask layer. This function has the setting to remove thin necks of the silkscreen that are thinner than the specified thickness.
  • Copper balance
    To align the copper balance on PCB, the selected polygons can be converted into a set of shapes distributed over the area of a given size and pitch between them. Available in square, round and rhombus shapes. This function has a setting to display only whole parts.
  • QR Encoder

    On the silkscreen layers, you can place a ready-made QR code converted from the specified text. The panel has a real-time display of the code. The function supports QR, DataMatrix and Aztec code types, and you can also specify the size and inversion to insert on the PCB.

Board Assistant

Another completed project by our team
Board Assistant is the only software solution that can prepare a complete set of design documentation in 20 minutes, which usually takes about 80 working hours.

LINK
ГлавКон
The company "GlavKon", being the official representative of Altium, has set a goal to improve the quality of the issued design documentation, automate this process and adapt it to the standards adopted in our country.

For this we created BOASTOOLS and we continue to improve our product. For more than 5 years, GlavKon has been providing a high level of expertise, technical support and support 24/7, 365 days a year.

HOW CAN I SUBMIT AN IDEA FOR A NEW TOOL?

1
join the Telegram group and write to us
2
Email info@glavkon.com
3
Call by phone
+7 812 922 28 98
You can also send a request to info@glavkon.com or call +7 812 922 28 98
